Green Energy-SOREX WELDING

Green Energy

SOREX WELDING electrode and wire design could provide low hydrogen, high deposition rate and impact toughness at low temperature. To fulfill offshore wind requirement, SOREX not only approved by various naval classification certificates (ABS, BV, CCS, CR, DNV-GL, KR, LR, NK, RINA PRS, JIS) but also approved by CPR-CE MARK.

View：

SL-58

Model : SL-58

490N/mm2級高張力鋼SMAW銲接
AWS A5.1 E7018
JIS Z3211 E4918
EN ISO 2560-A E 42 3 B 3 2
GB T5117 E5018

SLH-58

Model : SLH-58

490N/mm2級高張力鋼SMAW銲接
AWS A5.1 E7018-1 H4
JIS Z3211 E4918
EN ISO 2560-A E 46 4 B 3 2 H5
GB T5117 E5018

SS-309L

Model : SS-309L

不銹鋼SMAW銲接
AWS A5.4 E309L-16
JIS Z3221 ES309L-16
EN ISO 3581-A E 23 12 L R 1 2
GB T983 E309L-16

SFC-71M

Model : SFC-71M

490N/mm2級高張力鋼FCAW銲接
AWS A5.18 E70C-6C/6M
AWS A5.36 E70T15-C1/M21-CS1
JIS Z3313 T 49 4 T15-0 C/M A-U
EN ISO 17632-A T42 2 M C1/M21 3 H5
GB --

SFC-71

Model : SFC-71

490N/mm2級高張力鋼FCAW銲接
AWS A5.20 E71T-1C/1M
AWS A5.36 E71T1-C1/M21 A0-CS1
JIS Z3313 T 49 2 T1-1 C/M A-U
EN ISO 17632-A T42 2 P C1/M21 1 H5
GB T10045 E501T-1/1M

SFC-81M

Model : SFC-81M

低合金耐低溫鋼FCAW銲接
AWS A5.28 E80C-G
JIS --
EN ISO 17632-A-T46 6 Z M C1/M21 3 H5
GB --

SFC-81Ni1

Model : SFC-81Ni1

低合金耐低溫鋼FCAW銲接
AWS A5.29 E81T1-Ni1C/M
AWS A5.36 E81T1-C1/M21 A2-Ni1
JIS Z3313 T 55 3 T1-1 C A-N2
EN ISO 17632-A T46 3 1Ni P C1/M21 1 H5
GB T17493 E551T1-Ni1

SFC-81K2

Model : SFC-81K2

低合金耐低溫鋼FCAW銲接
AWS A5.29 E81T1-K2 C/M
AWS A5.36 E81T1-C1/M21 A8-K2
JIS Z3313 T 55 6 T1-1 C A-N3
EN ISO 17632-A T46 6 1.5Ni P C1/M21 1 H5
GB T17493 E551T1-K2

SFC-309L

Model : SFC-309L

不銹鋼FCAW銲接
AWS A5.22 E309LT1-1/-4
JIS Z3323 TS309L-FC1
EN ISO 17633-A T 23 12 L P C1/M21 2
GB T17853 E309LT1-1

SFC-2209

Model : SFC-2209

不銹鋼FCAW銲接
AWS A5.22 E2209T1-1/-4
JIS Z3323 TS2209-FC1
EN ISO 17633-A T 22 9 3 N L P C1/M21 2
GB T17853 E2209T1-1

SF-66 x SW-60G

Model : SF-66 x SW-60G

≧550N/mm2級高張力鋼單層、多層SAW銲接
AWS A5.23 F8A8-EG-G
JIS Z3183 S584-H
EN ISO 14171-A S 46 6 FB S3Si
GB --

SFC-71J

Model : SFC-71J

490N/mm2級高張力鋼FCAW銲接
AWS A5.20 E71T-1C/M-J
AWS A5.36 E71T1-C1/M21 A4-CS1
JIS Z3313 T 49 4 T1-1 C/M A-U
EN ISO 17632-A T46 4 P C1/M21 1 H5
GB T10045 E501T-1L/1ML

SF-66 x SW-M12K

Model : SF-66 x SW-M12K

490N/mm2級高張力鋼單層、多層SAW銲接
AWS A5.17 F7A4/P4-EM12K
JIS Z3183 S502-H
EN ISO 14171-A S 42 5 FB S2Si
GB T5293 F5A4/P4-H08MnA

SF-66 x SW-H12K

Model : SF-66 x SW-H12K

490N/mm2級高張力鋼單層、多層SAW銲接
AWS A5.17 F7A8/P8-EH12K
JIS Z3183 S502-H
EN ISO 14171-A S 46 5 FB S3Si
GB --

SF-65 x SW-M12K

Model : SF-65 x SW-M12K

490N/mm2級高張力鋼單層、多層SAW銲接
AWS A5.17 F7A2-EM12K
JIS Z3183 S502-H
EN ISO 14171-A S 42 3 AB S2Si
GB T5293 F5A3-H08MnA

SMG-60

Model : SMG-60

≧550N/mm2級高張力鋼MIG銲接
AWS A5.28 ER80S-G
JIS Z3312 G 55 A 3 U C 3M1
EN ISO 16834-A G 55 3 C1/M21 Z
GB T8110 ER55-G

SMG-60N

Model : SMG-60N

≧550N/mm2級高張力鋼MIG銲接
AWS A5.28 ER80S-G
JIS --
EN ISO 14341-A-G 46 6 C1/M21 Z H5
GB --
